An internal view of the main heliostat. Shown is the cover glass cell and mechanical actuator for the aperture shutter. The 8" F/15 objective is mounted behind this shutter. The tube passes through the ceiling of the lab/classroom housed below where the SCRIBS set up is located. From here, the shutter can be remotely adjusted.
|
||||||||||||||
